AssistX Mobil
AssistX Mobil
HMV-Nr 52.40.03.4001
Secure and flexible: The wireless call system
NEW: HMV-Nr 52.40.03.4001
Our secure, radio-based call system AssistX Mobil is listed in the list of medical aids (HMV) of the statutory health insurance companies as a nursing aid with the HMV number 52.40.03.4001.
The AssistX Mobil can not only be prescribed by a doctor, but also recommended by nursing staff according to § 40 Abs. 6 SGB XI and thus the costs can be covered by the GKV.
Our AssistX Mobil
AssistX Mobil is a safe, flexible, wireless call system for intensive care at home, in residential groups, homes and clinics. A wide variety of sensors and switches, but also communication aids and medical devices can be used to trigger a call. Multiple transmitters can be combined with one or more receivers.
Security
the call that is received safely
Our Call System is a lot more than a simple pager! It's particularly safe: the transmitters and receivers use a special frequency and meet all requirements of the German standard DIN VDE 0834. Every call is confirmed and cannot be lost. Continuous monitoring of the battery status and range guarantee perfect functioning. Unplugging a cable or other changes also trigger an alarm. All activities are logged in the receiver.
Assistive Call Activation
Any sensors or buttons can be connected via the AssistX Port. External devices with a call output, e.g. ventilators, can be used as a trigger. Customized according to needs and for each user.
AssistX ITX
The multi-port transmitter
AssistX ITX is a multi-port transmitter for the AssistX Mobile call system, specially designed for use in long term intensive care.
The Function: The Staff Call
with the AssistX Mobil Transmitter
By long pressing the middle red button on the AssistX Mobil transmitter, a staff call can be triggered. This requires updating the AssistX call system to the latest firmware.
ProX
proximity switch
RX One
easywave radio receiver
Hy Pneumax
sipp and puff switch
Devices
for communication
AS One
acoustic switch
Ventilators
and pulse oximeter
Kajo NC
the secure Button
Buttons
all kinds
Multi User
One for all, all for ...
For use in residential groups, in small nursing homes and in clinical environments, several transmitters can be combined with one or multiple receivers. The receivers recognize when another has already confirmed the call. A name can be assigned to each transmitter so that you can immediately see who needs help. Optional repeaters increase the range in larger buildings.
AAC
Extend with a secure call
A communication device enables conversation with its voice output and in writing. With AssistX Mobil it can be expanded with a secure call function. The AAC device only needs to have an infrared transmitter, which is usually installed. A safe call can be activated with eye control, head or mouth movements.
Accessories
For every day use
In everyday life it can get very busy. Charging the batteries, mounting and connecting to other devices must be very easy. Proven accessories are the key to trouble-free operation.
Dock
charging dock
Device Mounting
flexible attachment
S-Charger
secure charging
Interface-Wire
for external devices
AssistX Mobil Repeater
EXTENDED RANGE
In large facilities and buildings, it is often important to significantly increase the range of the AssistX Mobil call system. It's easy with the AssistX Mobil Repeater! Simply connect, switch on, ready. Up to 8 repeaters can be used in one system, they organize themselves, no settings are necessary. A buffer battery ensures safe function even in the event of a power failure.
HMV-No 52.40.03.5003
Wandhalterung HMV-No 52.99.01.2004
More Information
and technical details
- HMV-Nr 52.40.03.4001
- Secure wireless call system according to DIN VDE 0834
- Transmitter is equipped with an AssistX port and an IR sensor
- Battery and function monitoring of the transmitter
- Range monitoring
- Acknowledgement by soothing lamp function
- Adjustable volume
- Optical and acoustic signaling
- Vibration signaling
- Social Alarm Frequency
- Group: Several transmitters can be *interconnected to several receivers
- An individual name can be assigned to each transmitter.
- Large color display in the receiver
- Battery life: Depending on the inserted sensor, up to several days (transmitter); 9 - 20 h (receiver)
- Receiver configurable by display menu or PC
- Dimensions: approx. 65 x 119 x 26.5 mm
AssistX Mobil – Call System:
AssistX Interface cables for pulse oximeter, ventilators,…:
20542-01
Für Pulsoximeter/For pulse oximeter Nellcor N560
20542-02
Für Pulsoximeter/For pulse oximeter Nellcor PM100N
20542-03
Für Pulsoximeter/For pulse oximeter Massimo Rad-8
20542-04
Für Pulsoximeter/For pulse oximeter Nonin Avant 9600
20542-05
Für Pulsoximeter/For pulse oximeter VitaGuard VG310+2100+3100
20541-01
Für Beatmungsgerät/For ventilators Trilogy 100+200 Philips
20541-02
Für Beatmungsgerät/For ventilators Beatmungsgerät Astral 100+150, Stellar 100+150, Resmed
20541-03
Für Beatmungsgerät/For ventilators Beatmungsgerät Vivo 50+55+60+65,Breas
20541-04
Für Beatmungsgerät/For ventilators Respironics V60, Philips
20541-05
Für Beatmungsgerät/For ventilators Ventilogic plus/LS, Löwenstein
20541-07
Für Beatmungsgerät/For ventilators LM Luisa
20543-01
Für Bettalarm/For bed alarm Epi-Care 3000
20543-02
Für Bettalarm/For bed alarm Emfit
20543-03
Für Ernährungspumpe/For nutrition pump Nestlé Compat Ella
20543-04
Für Ernährungspumpe/For nutrition pump Fresenius APPLIX
AssistX Sensors:
Hygienic pneumatic switches:
AssistX Buttons NC:
Mounting AssistX:
20524
Flexibler Gerätehalter für/flexible mounting for AssistX Mobil Gelenkarm/mounting arm
20365
HMV-Nr 52.99.01.2002 Gerätehalter für/mounting for AssistX Mobil am Gelenkarm/on mounting arm
20366
HMV-Nr 52.99.01.2002 Gerätehalter für/mounting for AssistX Mobil für/for Rehadapt L3D 10mm.
20097
HMV-Nr 52.99.01.2001 Gelenkarm für/mounting arm for AssistX AS one, AssistX ABL/BL
20459
HMV-Nr 52.99.01.2004 Montageplatte magnetisch für/magnetic mounting plate for AS one, IR one, RX one, ABL & Remobox
20458
Wandhalterung magnetisch für/magnetic wall mount for RemoBox, AS one, ABL
AssistX Accessoires:
20164
IR-Fernbedienung für/IR remote control for IR one & AssistX TX
20527
Set: stereo & mono Kabel/cable
20206
A-micro USB-Kabel grün/A-micro USB cabel green
20205
4pol. Klinkenstecker/jack plug 2m
20457
HMV 52.40.03.5002 kompatibler Empfänger für Easywave-Geräte/compatible receiver for Easywave devices
AssistX Demo-Kits:
18001
MOBIL+CALL
18002
MOBIL INTENSIV
18003
FULL SET
Reseller & Distributors
Are you looking for purchasing this product and are you looking for the right specialist reseller?
